Swift Internal Door Operator

Main Menu

Overhead Door Closing Solutions

The brushless motor ensures near silent operation

The Swift is our internal door operator. With a tiny footprint, this operator looks at home in any residence. The brushless motor ensures near-silent operation while longevity is guaranteed. The Swift can cope with internal doors where the wind is not an issue. Designed to cope with virtually any reveal found, the Swift is as versatile as it is elegant. The Swift has its fixing plate, as stability is essential while the sightlines are kept to a minimum.

Contact Sale Department

0845 094 5636

Swift Internal Options

SWIFT B
Has the same functions as the Swift, but includes battery back up without increasing the size of the operator.
SWIFT F
We have adapted the Swift S operator to have a fire certificate rating of 30/30 and tested in the UK.

Swift Specifications

BODY FINISH

Satin Anodised Aluminium grey end caps

OPENING DIRECTION

In or Out

WEIGHT

5 KGS

OPENING ANGLE

Up to 110 degrees

Swift Articulated (Push) Arm

DIMENSIONS

Height: 60mm Length: 420mm Depth: 74mm

LEAF DIMENSIONS

650mm – 1200mm

POWER SUPPLY

13 AMP switched fused spur

ELECTRIC LOCK POWER OUTPUT

24V Max. 5A

NUMBER OF DOOR LEAVES

1 Leaf / 2 Leaves

MAX PAYLOAD

90 KGS

POWER USAGE

40 Watts

SPRING TENSION

EN3

Swift Rigid (Pull) Arm

More Products

  • SWIFT

    The Swift is our internal door operator. With a tiny footprint, this operator looks at home in any residence. The brushless motor ensures near silent operation while longevity is guaranteed. The Swift can cope with internal doors where wind is not an issue.

    Details
    SWIFT

  • GLIDE

    The Glide sliding door operator provides exceptional performance in all scenarios. It offers a wide range of innovative options to meet the needs of all environments, with its modular design and mechanical features that create a flexible, functional, slimline, sliding door system.

    Details
    GLIDE

  • GLIDE HD

    Sed ut perspiciatis unde omnis iste natus error sit voluptatem, totam rem aperiam, eaque ipsa quae ab illo inventore et quasi architecto beatae vitae dicta sunt explicabo.
    Details
    GLIDE HD

  • GLIDE T

    Sed ut perspiciatis unde omnis iste natus error sit voluptatem, totam rem aperiam, eaque ipsa quae ab illo inventore et quasi architecto beatae vitae dicta sunt explicabo.
    Details
    GLIDE T

  • SATURN

    Sed ut perspiciatis unde omnis iste natus error sit voluptatem, totam rem aperiam, eaque ipsa quae ab illo inventore et quasi architecto beatae vitae dicta sunt explicabo.
    Details
    SATURN

  • ORBIT

    Sed ut perspiciatis unde omnis iste natus error sit voluptatem, totam rem aperiam, eaque ipsa quae ab illo inventore et quasi architecto beatae vitae dicta sunt explicabo.
    Details
    ORBIT

  • ORBIT ALL GLASS

    Sed ut perspiciatis unde omnis iste natus error sit voluptatem, totam rem aperiam, eaque ipsa quae ab illo inventore et quasi architecto beatae vitae dicta sunt explicabo.
    Details
    ORBIT ALL GLASS

  • ALUMINIUM

    Sed ut perspiciatis unde omnis iste natus error sit voluptatem, totam rem aperiam, eaque ipsa quae ab illo inventore et quasi architecto beatae vitae dicta sunt explicabo.
    Details
    ALUMINIUM

  • BARRIER RAILS

    Sed ut perspiciatis unde omnis iste natus error sit voluptatem, totam rem aperiam, eaque ipsa quae ab illo inventore et quasi architecto beatae vitae dicta sunt explicabo.
    Details
    BARRIER RAILS

  • POCKET SCREEN BARRIERS

    Sed ut perspiciatis unde omnis iste natus error sit voluptatem, totam rem aperiam, eaque ipsa quae ab illo inventore et quasi architecto beatae vitae dicta sunt explicabo.
    Details
    POCKET SCREEN BARRIERS
    Quality you can trust.

    The Swift range has been developed by Prosale to ensure a robust and reliable operator, that has the aesthetics that wouldn’t look out of place internally.

    Features
    • Activation Sensors

    • Touch Pads

    • Digidor Logic Sensor

    • Winter setting (reduced opening)

    • Electric lock as an option

    • Battery back up as standard

    Features

    Can work with non-thermally broken, thermally broken sections, all glass or slimline units

    Note: Pocket screens can not be used with telescopic doors (as per BS EN16005)
